ADM9

ADM9
Magnifying lens Click on image to enlarge
Select Insert & Channel



ADM9 stair edging (nosing) comprises an aluminium channel with a choice of insert material. It can be used in conjunction with floorcoverings from all major manufacturers and is suitable for all commercial and most industrial applications.

This bullnose, single channel, ramp back profile features a 70mm tread and 55mm riser to meet the guidance in Approved Document M and BS 8300-2:2018. It is ideal for use where there are no surface floorcoverings or with resilient flooring. When used with resilient flooring ADM9 should be installed on top of the floorcovering.

Supplied in mill finish aluminium as standard. Anodised, polished or chromed options also available upon request.
